Piston Ölçüleri(Piston Dimensions)
A : 55.370
B- : 19.800
BØ : 40.000
BX : 3.000
BY : 1.500
D : 86.370
E : 16.100
Pim : 26 x 65
Piston Özellikleri(Piston Features)
Gözarası Konik
(Conical Eye Gap)
Piston Parça No
(Piston Part No)
87-252500-14
87-71309-STD2
– 0,20 mm Kısa (Short)
87-252500-12
87-71309-STDA
87-252507-12
87-71309-050A
87-252511-12
87-71309-100A
87-862800-22
87-71309-STDB
87-862807-22
87-71309-050B
Segman Seti(Ring Set)
06-252500-20-STD
06-252507-20-0,50 mm
06-252511-20-1,00 mm
| 2.000 |  | CR | KV1 |
| 2.000 |  | STD | |
| 3.000 |  | STD |
06-862800-20-STD
06-862807-20-0,50 mm
| 2.000 | | CR | KV1 |
| 2.000 | | GOE | |
| 3.000 | | GOE |
Silindir Gömleği
(Liner)
14-021040-00-D
B : 94.100
L : 175.500
D : 99.000
C : 5.000
14-021041-00-D
B : 94.600
L : 175.500
D : 99.500
C : 5.500
Dış Çap 0,50mm Farklı
(Outside Diameter
0,50mm Different)
14-021041-00 D
Dış Çap 0,50mm Farklı
(Outside Diameter
0,50mm Different)
14-029750-00-DH
B : 94.010
L : 175.500
D : 98.900
Silindir Kit(Assembly Set)
Piston-Blok Montaj Yüksekliği(Piston – Block Assembly Height)
1 Kertik (Notch) 0.59 / 0,69
2 Kertik (Notch) 0,69 / 0,76
3 Kertik (Notch) 0.76 / 0.83
04179914, 04271277, 04178304, 04178338, 04170633, 04174260, 04174711, 04175135, 04179524, 04179525, 04179526, 04179541, 8725250010, 0997300, 0997200, 91260600
